Note: The structure of high‑pressure three‑way valves varies among manufacturers. Details of product components are not shown in this solution. Custom non‑standard automation solutions can be provided according to your actual products. This case only displays partial assembly procedures. Please feel free to contact us for detailed solutions and equipment documents.
| No. | Process | Description | Operator | Remarks |
|---|---|---|---|---|
| 1 | Automatic feeding of valve body | 0.3 | Vibratory bowl feeding | |
| 2 | Material detection | / | 0 | |
| 3 | Automatic silicone oil dispensing | / | 0 | Automatic silicone oil injection |
| 4 | Automatic feeding of valve core | 0.3 | Vibratory bowl feeding | |
| 5 | Automatic valve‑core pressing & angle‑locking rotation | / | 0 | |
| 6 | Automatic UV glue dispensing | / | 0 | |
| 7 | Automatic feeding of high‑pressure threaded connector | 0 | Vibratory bowl feeding | |
| 8 | UV curing oven | / | 0 | UV oven for glue curing |
| 9 | Automatic unloading | / | 0 | Unload to pallet |
1 set of automatic assembly machine 3 sets of material vibratory bowl feeders
| Item | Brand | Remarks |
|---|---|---|
| Linear guide & slider | HIWIN(Taiwan), AIRTAC | Genuine original |
| PLC | Delta | Genuine original |
| Pneumatic components | AIRTAC / EMC | Genuine original |
| Motion controller | Synrit | Genuine original |
| HMI | Weinview, Delta | Genuine original |
| Relay | Omron | Genuine original |
| Power supply | Delta, Meanwell | Genuine original |
| Asynchronous motor | Jingyan | Genuine original |
| Servo motor | KOSI / HCFA | Genuine original |
| Stepper motor | Xingfengyuan | Genuine original |
| Bearing | NSK, HRB | Genuine original |
| Sensor | Panasonic or equivalent brand | Genuine original |
| Magnetic switch | AIRTAC | Genuine original |
